Furring Channel Machine is a dedicated cold-rolling forming production line designed for the continuous production of metal coil keel channels. These profiles are widely used in modern construction to create smooth ceilings, straight walls, and provide a reliable framing structure for drywall, cladding, and building panels.
This machine balances speed and consistency, combining precision roll forming with optional in-line punching and automatic cutting functions to produce keel channels with high dimensional accuracy and consistent quality.
Whether you are producing standard sizes or custom profiles, this system helps manufacturers increase production efficiency, reduce labor costs, and meet the demands of high-demand construction projects with reliable output.
Main Components
| Decoiler | Holds and feeds steel coils smoothly into the line |
| Leveling System | Ensures flat, uniform material before forming |
| Furring Channel Machine Unit | Precision-engineered rollers shape steel into into different profiles with accuracy |
| Punching | The flat strip passes through the pre-punching station, where holes/slots are stamped out at precise intervals |
| Hydraulic Cutting System | Provides fast, clean, and burr-free cuts to required lengths |
| Control System (PLC + Touch Screen) | User-friendly interface for automatic operation and easy adjustments |
| Output Table | Collects finished products for efficient handling and packaging |
Key Features
- High Efficiency: Produces long, continuous lengths at high speeds.
- Consistency & Precision: Ensures every channel has identical dimensions and mechanical properties, which is critical for easy installation.
- Customisation: Can be tooled to produce various channel sizes, web depths, and flange widths.
- Integrated Operations: Can include in-line punching , notching, and embossing in a single, automated process.
- Low Labour Cost: Automates a fabrication process that would otherwise be slow and labour-intensive.
Technical Specifications
| Material | Type | CRS, GI, Aluminum |
| Thickness(mm) | 0.4-1.2 Max | |
| Yield Strength(Mpa) | 235 | |
| Forming Speed(m/min) | 15-25(customized) | |
| Roller Station | 10-16 Depends | |
| Roller Material | GCr15 hardened to HRC58-62° | |
| Shaft Material | 45# steel with hard chrome treatment | |
| Roller Driven Type | Chain transmission/Gearbox | |
| Shaft Material | 45# steel with heat treatment | |
| Shaft Diameter | Ø60-75 mm | |
| Control System | PLC+Touch screen and button | |
| Main Machine Power(KW) | 7.5 | |
| Hydraulic station Power(KW) | 7.5 | |
| Machine Weight(Kg) | 5000 | |
| Machine size(m) | 5.5×1.8×1.9 Depend on final design | |
FAQ
What is Furring Channel Machine?
Furring Channel Machine is industrial equipment from Metoform designed for continuous metal forming and production. It helps manufacturers improve efficiency, consistency, and output quality for construction-related profiles and components.
What materials can it process?
Common materials include GI, PPGI, Galvalume, and other suitable steel coils. Final thickness and yield strength depend on the machine configuration and customer requirements.
Can the machine be customized?
Yes. Metoform can customize roll tooling, punching layout, cutting system, and control configuration based on your drawings and production needs.
What industries is this equipment suitable for?
It is suitable for metal fabrication, construction materials manufacturing, and related industrial production lines.
How fast is the machine?
Typical forming speed depends on profile complexity and material thickness. Metoform lines are designed for stable continuous production with practical industrial output.
Do you provide installation and after-sales support?
Yes. We provide technical guidance, commissioning support, and after-sales service to help customers start production smoothly and maintain stable operation.
